CNC Lathe Machine PI 809-11

The CNC Lathe Machine is a flat-bed CNC lathe designed for general metal machining applications.
SKU 809-11 Category

Description

  • Designed for cutting a wide range of ferrous and non-ferrous metals, this bandsaw offers a robust structure, stable operation, reliable performance, and high cutting accuracy. It is an ideal solution for medium- and small-batch production in workshops and manufacturing facilities
  • Features:
    • Hydraulic saw frame feed with infinitely variable speed contro
    • Hydraulic vise clamping for secure workpiece holding
    • Precision blade guiding system with rolling bearings and carbide guide blocks
    • Optional powered roller table for efficient material feeding
  • Swing over bed: 400 mm
  • Swing over cross slide: 210 mm
  • Distance between centers: 750/1000/1500/2000 mm
  • Spindle bore: 52 (Optional 80) mm
  • Spindle bore taper: MT6
  • Spindle nose type: A2-6(A2-8)
  • Spindle speed steps: Stepless
  • Spindle speed range: 1800 mm
  • Turret/tool post: Electric 4 position
  • Tool size: 20*20 mm
  • X axis travel: 200 mm
  • Z axis travel: 500/750/1250/1750 mm/min
  • X axis rapid traverse: 4000 mm/min
  • Z axis rapid traverse: 6000 mm
  • Tailstock quill diameter: 65 mm
  • Tailstock quill taper: MT4
  • Tailstock quill travel: 140 mm
  • Main spindle motor: 5.5 kw
  • Coolant pump motor: 0.125 kw
  • Weight for 750: 1550 kg
  • Weight for 1000: 1650 kg
  • Weight for 1500: 1850 kg
  • Weight for 2000: 2050 mm
  • Dimension for 750: 2200*1650*1700 mm
  • Dimension for 1000: 2500*1650*1700 mm
  • Dimension for 1500: 3000*1650*1700 mm
  • Dimension for 2000: 3500*1650*1700 mm
